KAF-HD

The heavy-duty base model — a 15A aluminium pedal with a high-visibility yellow finish and IP65 sealing, available in multiple gangs.

General Features

Material	Aluminium alloy (warning yellow), baked-enamel surface
Rated	15A / 250VAC (resistive)
Contact Form	Each 1C / each 1a (1a+1b / 2a+2b optional)
Internal Switch	Z15G-10B; 24K gold-plated contacts
Contact Resistance	≤30mΩ (initial)
Insulation Resistance	≥100MΩ (500VDC test)
Dielectric Strength	2000VAC, 1 min
Mechanical Life	≥1,000,000 cycles
Electrical Life	≥500,000 cycles
Protection Rating	IP65

Structural Features

❶Pedal & Base	Aluminium alloy in high-visibility warning yellow, baked-enamel surface; IP65 sealed.
❷Micro Switch	Z15G-10B heavy-duty switch; 24K gold-plated; UL, c-UL, CCC, CE certified.
❸Spring Cable Lock	Spring-type cable lock for high tensile strength.
❹Marking	Optional custom laser marking.
❺Cable	RVV 0.5–0.75mm² × 2m (3m/5m optional); heavy-duty 7-core.

Installation Mode

Bolt-mounted. Single/twin/triple gang (HD101/HD201/HD301); audio, serial and USB interfaces and custom laser marking available.

Dimensions & Wiring

Variants: KAF-HD101 / HD201 / HD301 / -A·D·U / laser marking
